Most frequently asked questions

1. How to configure Plesk mail in Android

   Here is a step-by-step guide to help you configure Plesk mail in Android.




   Step 1




   Open the Gmail app, go to ‘Settings’ and tap ‘Add account’.









   Step 2




   Select ‘Personal (IMAP/POP)’.









   Step 3




   Insert email address and select ‘Manual setup’.









   Step 4




   Select Personal (IMAP) or Personal (POP3) according to your preference.









   Step 5




   Enter your password.









   Step 6




   On the incoming settings screen select authentication ‘SSL/TLS (Accept all certificates)’.









   Step 7




   The incoming server settings will be validated.









   Step 8




   On the outgoing server settings screen select authentication ‘SSL/TLS (Accept all certificates)’.









   Step 9




   Select the prefered synchronization options.














   Step 10




   Tap your ‘Inbox’ to start reading and writing emails.






2. How to install the php-mcrypt module on a Plesk server

   Question




   How to install the php-mcrypt module on a Plesk server?




   Answer




   Notes: The solution in this article is applicable to system PHP versions (Up to 7.1) supplied by OS vendor.

   Plesk PHP handlers up to 7.1 are shipped with the mcrypt module by default. PHP handlers provided by Plesk can be installed via Plesk Installer and selected at Domains > example.com > PHP settings.

   The mcrypt module is deprecated since PHP 7.1 and is moved out from core into PECL:
           PHP RFC: Deprecate (then Remove) Mcrypt
           PHP: Deprecated features in PHP 7.1.x






   1.


      Connect to a Plesk server via SSH.





   2.


      Install the module:





      •


        on CentOS/RHEL-based distributions:




        The php-mcrypt package is available in RPMforge and EPEL repositories. Add the repository to the server and install the package using the yum utility. In this example, we are using the EPEL repo:




        # yum install epel-release
        # yum install php-mcrypt





      •


        on Debian/Ubuntu-based distributions:




        Find the system PHP version:




        # php -v




        Run the command:





        •


          if PHP 5.x version is installed:




          # apt-get install php5-mcrypt





        •


          if PHP 7.x version is installed:




          # apt-get install php-mcrypt













   3.


      To make the mcrypt extension available for existing websites, update PHP settings for all domains with the command:




      # /usr/local/psa/bin/php_settings -u




      This extension will also appear in Plesk at Tools & Settings > PHP Settings > [php] by OS vendor.






3. Windows: Accessing Your Server with Remote Desktop

   This article explains how to use Remote Desktop to access your Windows server’s desktop from anywhere in the world.




   Remote Desktop from a Windows Computer






   1. Click the Start button.


   2. Click Run…


   3. Type “mstsc” and press the Enter key.


   4. Next to Computer: type in the IP address of your server


   5. Click Connect.


   6. If all goes well, you will see the Windows login prompt.






   Remote Desktop from a Linux Computer with RDesktop






   1. Open a command shell using xterm


   2. Type ‘rdesktop’ at the command prompt to see if you have rdesktop installed


   3. If rdesktop is installed, then proceed.  Otherwise, you will need to install the rdesktop package for your flavor of Linux.


   4. Type ‘rdesktop’ followed by your server’s IP address.  Then press Enter.



      • Example:
        $ rdesktop 72.52.246.40






   5. If all goes well, you will see the Windows login prompt.






   Remote Desktop from Mac OS X






   1. Using Microsoft Remote Desktop (Mac OS X versions 10.9 and later):



      • Install Microsoft Remote Desktop from the Mac App Store.


      • Click the New button or use the shortcut Command + N to set up a connection to your server with the following settings:








        • PC name: You can use your server’s IP address or its hostname (if the hostname has an appropriate DNS record and resolves).


        • User name: To access the admin account, use "root" or “Administrator”.


        • Password: Enter the Administrator password.


        • Configure full-screen and multi-monitor settings to your preference.






      • Once you’ve filled in the appropriate settings, close the Edit Remote Desktops window.


      • Select your connection under My Desktops and press the Start button in the menu to connect (or simply press the return key on your keyboard).








      • If your server uses a self-signed SSL certificate, a message will be displayed as Remote Desktop is negotiating credentials. You can either press Continue to proceed with the connection or, to permanently store the certificate and connect directly in the future, click Show Certificate and then check the box next to Always trust … before clicking Continue to proceed.






   2. Using CoRD (Mac OS X versions 10.5 through 10.8 only):



      • Download and install the CoRD application here.


      • Open the application and click on the File menu, then New Server


      • You will be presented with a window where you can specify information about the server you are connecting to.


      • Enter the server’s hostname or IP address in the Address field.


      • You can alter the other settings in this window if you wish but all you need to start the connection is the address.


      • When you are finished making changes, press the enter/return key on your keyboard or simply close the new server window.


      • Your new server profile will appear in the list to the left side of the application. Double click on it and you will start the connection to your server.






   3. Using the Microsoft RDP Tool (Mac OS X versions prior to 10.7 only):



      • Download and install the Microsoft Remote Desktop Connection Client for Mac here.


      • When you open the application, you will be prompted for the “Computer:” you would like to connect to. You can enter the server’s hostname or IP address.


      • After you click Connect the client will ask for your user name and password. If it fails to connect, you can try again inside the remote connection window.







4. What is Reverse DNS?

   Reverse DNS (rDNS) is name resolution that looks up an IP addresses to obtain a domain name, performing the opposite function of the DNS server, which turns domain names into IP addresses.




   Reverse DNS can be used as a spam filter. Typically, spammers use invalid IP addresses, that is, ones that do not match domain names. A reverse DNS program looks up the IP address of an incoming message and, if no valid domain name is found, the server blocks the message. Although reverse DNS is fairly effective for filtering spam, it also often blocks valid emails.




   Our administrators configure reverse DNS on all of our email servers. If you administrate your own server, you can contact your IP address's provider to configure reverse DNS.

5. How to disable directory browsing globally on whole WHM/cPanel server

   o disable directory browsing/listing on whole server, follow these simple instructions:




   1. Log into WHM
   2. Service Configuration –> Apache Configuration
   3. Global Configuration
   4. Scroll down to Directory ‘/’ Options
   5. Un-tick Indexes option (see picture)
   6. Then press Save button below
   7. Finally, rebuild by clicking rebuild apache conf button and that’s it…



6. Setting up Nameserver DNS Using cPanel/WebHost Manager

   cPanel's WebHost Manager® (WHM) lets you use your own domain name as a nameserver for websites your server hosts. To use your domain name, you have to set up a WHM Account for it first.




   To Set up Nameserver DNS Using cPanel/WHM






   1. Log in to WebHost Manager using root for your username and your server's password at https://yourserverip:2087, where yourserverip is your server's IP address.


   2. Click DNS Functions.


   3. Click Edit DNS Zone.


   4. Select the domain name you want to use, and then click Edit.


   5. For the two rows with the menu displaying NS, edit the right-most columns to ns1.your domain name. and ns2.your domain name., respectively.


       Note: You have to enter a "." after your nameserver in this section for the DNS to work properly.





   6. In the Add New Entries Below this Line section, do the following in the first row:



      • First field: Type ns1


      • Second field: Type 14400


      • Third field: Select A


      • Fourth field: Enter your server's IP address





      Then, in the second row, do the following:





      • First field: Type ns2


      • Second field: Type 14400


      • Third field: Select A


      • Fourth field: Enter your server's IP address





       Note: Do not enter a "." after your ns1 and ns2 entries in this section.





   7. Click Save.


       Note: DNS can take 24-48 hours to propagate once these changes have been made.






7. How to Install MySQL on CentOS 7

   MySQL is a popular database management system used for web and server applications. However, MySQL is no longer in CentOS’s repositories and MariaDB has become the default database system offered. MariaDB is considered a drop-in replacement for MySQL and would be sufficient if you just need a database system in general.




   Before You Begin







   1.


      Ensure that you have followed the Getting Started and Securing Your Server guides, and the Linode’s hostname is set.




      To check your hostname run:




      hostname

      hostname -f






      The first command should show your short hostname, and the second should show your fully qualified domain name (FQDN).





   2.


      Update your system:




      sudo yum update







   3.


      You will need wget to complete this guide. It can be installed as follows:




      yum install wget










   Install MySQL





   MySQL must be installed from the community repository.






   1.


      Download and add the repository, then update.




      wget http://repo.mysql.com/mysql-community-release-el7-5.noarch.rpm

      sudo rpm -ivh mysql-community-release-el7-5.noarch.rpm

      yum update







   2.


      Install MySQL as usual and start the service. During installation, you will be asked if you want to accept the results from the .rpm file’s GPG verification. If no error or mismatch occurs, enter y.




      sudo yum install mysql-server

      sudo systemctl start mysqld











   MySQL will bind to localhost (127.0.0.1) by default.






   Harden MySQL Server







   1.


      Run the mysql_secure_installation script to address several security concerns in a default MySQL installation.




      sudo mysql_secure_installation











   You will be given the choice to change the MySQL root password, remove anonymous user accounts, disable root logins outside of localhost, and remove test databases. It is recommended that you answer yes to these options. You can read more about the script in the MySQL Reference Manual.









8. How to change the location for Plesk backup files on a Linux server?

   By default, all backup data is stored in the directory /var/lib/psa/dumps.




   To change the default backup location, follow these steps:






   1.


      Connect to a Plesk server via SSH.





   2.


      Create a new directory for backups. In these example, we will use /plesk_backups:




      # mkdir /plesk_backups





   3.


      Set necessary ownership for the created directory:




      # chown psaadm:psaadm /plesk_backups





   4.


      Modify the backup location in the Plesk configuration file /etc/psa/psa.conf:




      4.1. Open the file /etc/psa/psa.conf in a text editor (for example, "vi" editor).




      4.2. Change the value of DUMP_D to the created directory from step 2:




      # Backups directory
      DUMP_D /plesk_backups




      4.3. Save the changes and close the file.




      4.4. Verify that the directory has been changed:




      # cat /etc/psa/psa.conf | grep -w DUMP_D
      DUMP_D /plesk_backups





   5.


      Move all backup data and the hidden .discovered directory from the old location to new:




      # mv /var/lib/psa/dumps/* /plesk_backups/
      # mv /var/lib/psa/dumps/.discovered/ /plesk_backups/





   6.


      Restart the "sw-cp-server" service:




      # service sw-cp-server restart


      From now all backup files will be stored in the directory /plesk_backups.



9. Configuring FTP Passive Mode to Plesk

   By default, Plesk allows only active FTP connections. This may result in customers being unable to connect to the server via FTP. To avoid this, we recommend enabling passive FTP. This topic explains how to enable passive FTP mode in Plesk for Linux.




   To enable passive FTP mode in Plesk for Linux:






   1. Log in to your server via SSH as the root user.


   2. Create the /etc/proftpd.d/55-passive-ports.conf file, add the following lines to it, and then save the changes:


      <Global>




      PassivePorts 49152 65535




      </Global>





   3. Run the following command:


      systemctl restart xinetd









   Now your Plesk server accepts passive FTP connections. If you have installed the Plesk Firewall and switched on its default configuration, you need to add a firewall rule allowing passive FTP:






   • Direction: Incoming


   • Action: Allow


   • Ports: TCP 49152-65535


   • Sources: (any host)









10. How to format a Linux Disk as Ext4 from the Command Line

    For the code, I’m just going to assume the drive is /dev/sdb. If you’re following this, make sure you’re using the correct drive name.




    Unmount The Drive




    Only needed if it’s been mounted already.




    sync
    umount /dev/sdb1




    Prepare the Drive




    Fire up fdisk




    fdisk /dev/sdb




    If you already have a filesystem on the disk, wipe it.




    Press d




    Now create a new primary partition.




    Press p




    Enter the partition number.




    Press 1




    It’ll now ask you to set the start and end cylinders on the disk. Just hit return for each to accept the defaults.




    Change the system type to Linux.




    Press t
    Enter 83




    Write the changes to disk (this can’t be undone).




    Press w




    Create the Filesystem




    Format the new partition using Ext4.




    mkfs.ext4 /dev/sdb1




    It’ll now go off and start writing the filesystem. This can take a bit of time, but it should give you an update on what’s being written.




    Mount Your Drive




    Now your partition has been created, you need to mount it somewhere to use it. Here I’m using /mnt/user/ext/.




    mount /dev/sdb1 /mnt/user/ext/

11. How to log in to MySQL using the Plesk MySQL "admin" password in plain text?

    Question




    It is not possible to log in to MySQL using a Plesk MySQL "admin" password in plain text:




    # mysql -uadmin -p"mysql_admin_password_in_plain" psa
    ERROR 1045 (28000): Access denied for user 'admin'@'localhost' (using password: YES)




    while login with cat works fine:




    # MYSQL_PWD=`cat /etc/psa/.psa.shadow` mysql -uadmin psa




    How to log in to MySQL using a Plesk MySQL "admin" password in plain text?




    Answer




    For security reasons, the Plesk MySQL "admin" password is encrypted and stored in the file /etc/psa/.psa.shadow.




    To log in to MySQL using the Plesk MySQL "admin" password without cat, use the encrypted string from the file /etc/psa/.psa.shadow:




    Note: Put the backslash symbol "\" before the sign "$":




    # mysql -uadmin -p"\$AES-128-CBC\$NP15ZIjr/iNnfjQ72gR8yA==\$uil2bGcV83uxvFihBxkSvA==" psa




    To connect from the MySQL Workbench use the plain text from the /etc/psa/.psa.shadow.

12. How to change virtual hosts location in Plesk for Linux?






    In Plesk for Linux, transvhosts.pl utility can be used to change the location for all virtual hosts:




    Warning: Plesk Onyx with SELinux enabled does not support custom vhosts directory, that would break your sites. This bug PPPM-6521 will be fixed in future Plesk updates.




    In Plesk for Linux, transvhosts.pl utility can be used to change the location for all virtual hosts:




    # /usr/local/psa/bin/transvhosts.pl --help




    In the following example, the location is changed to /home directory:




    # /usr/local/psa/bin/transvhosts.pl --dest-dir /home --correct-scripts




    Note: All the vhosts' content will be automatically moved into the new location.

13. How to configure Plesk mail in Outlook

    Here is a step-by-step guide to help you configure Plesk mail in Outlook.




    Step 1




    Open outlook and go to ‘File’.









    Step 2




    Click ‘Add Account’









    Step 3




    Select ‘Manual setup or additional server types’ and click ‘Next’.









    Step 4




    Select ‘POP or IMAP’ and click ‘Next’.









    Step 5




    Enter your User and Server information and click on ‘More Settings’ if you need to configure other Ports for incoming and outgoing mail server than the defaults.




    If using the default ports is okay, click next and skip to Step 7.









    Step 6




    Configure custom ports for Incoming and Outgoing mail servers in the ‘Advanced’ tab.









    Step 7




    Wait for the account settings test to complete and click ‘Close’.









    Step 8




    Click ‘Finish’ to exit the wizard and start using your email account.






14. How to configure Plesk mail in iOS

    Here is a step-by-step guide to help you configure Plesk mail in iOS.




    Step 1




    Go to Settings and tap ‘Mail, Contact, Calendars’.









    Step 2




    Select ‘Add account’.









    Step 3




    Select ‘Other’ from the list of email providers.









    Step 4




    Then tap ‘Add Mail Account’.









    Step 5




    Enter your Name, Email, Password and a short description and tap ‘Next’.









    Step 6




    Select IMAP or POP and enter your incoming and outgoing mail server details.









    Step 7




    Accept the SSL certificate. Tap Continue. This will appear twice, once for your incoming mail server and once for the outgoing one.









    Step 8




    Tap ‘Save’ to finish setting up your email.






15. How to install APCu module on Plesk server ?



    1.


       Connect to the server via SSH.





    2.


       Install required development packages:





       •


         For .deb-based OS (Ubuntu, Debian):




         # apt install plesk-php70-dev zlib1g-dev gcc





       •


         For .rpm-based OS (CentOS, RHEL, CloudLinux):




         # yum install plesk-php70-devel zlib-devel gcc








       Note: As an example, Plesk PHP 7.0 development package is installed. For a different version of PHP change php70 to the required version, for instance, php56





    3.


       Install APCu module:





       •


         For Plesk PHP 7.x:




         # /opt/plesk/php/7.x/bin/pecl install apcu





       •


         For Plesk PHP 5.x:




         # /opt/plesk/php/5.x/bin/pecl install apcu-4.0.11









    4.


       Enable APCu in PHP configuration:




       # echo "extension=apcu.so" > /opt/plesk/php/7.0/etc/php.d/apcu.ini





    5.


       Restart PHP service and refresh PHP handlers information:




       # service plesk-php70-fpm restart




       # plesk bin php_handler --reread





    6.


       Verify that the module is loaded and is working:




       # /opt/plesk/php/7.0/bin/php -i | grep apc.enabled
       apc.enabled => On => On






16. How to enable the Apache server statistics on a Plesk server



    1.


       Connect to a Plesk server via SSH.





    2.


       Check if "status_module" is loaded:





       •


         for CentOS/RHEL-based distributions:




         # httpd -M | grep status
         status_module (shared)





       •


         for Debian/Ubuntu-based distributions:




         # apache2ctl -M | grep status
         status_module (shared)




         If the output is empty, enable the "status" module in Plesk at Tools & Settings > Apache Web Server.









    3.


       Find out Apache version:





       •


         for CentOS/RHEL-based distributions:




         # httpd -v | grep version





       •


         for Debian/Ubuntu-based distributions:




         # apache2 -v | grep version









    4.


       To make status reports visible to your IP address (from which you access this page in a browser) and localhost, add the below code to the Apache configuration file (create a new file, if there is no):





       •


         CentOS/RHEL-based distributions:
             CentOS 7: /etc/httpd/conf.modules.d/status.conf
             CentOS 6: /etc/httpd/conf.d/status.conf





       •


         Debian/Ubuntu-based distributions: /etc/apache2/mods-enabled/status.conf




         In this example, we are allowing status reports to IP addresses 203.0.113.2, 203.0.113.3 and localhost:





         •


           for Apache 2.2:




           <IfModule mod_status.c>
               <Location /server-status>
                   SetHandler server-status
                   Order deny,allow
                   Deny from all
                   Allow from 127.0.0.1 localhost ip6-localhost 203.0.113.2 203.0.113.3
               </Location>
               ExtendedStatus On
           </IfModule>





         •


           for Apache 2.4:




           <IfModule mod_status.c>
               <Location /server-status>
                   SetHandler server-status
                   <RequireAny>
                       Require local
                       Require ip 203.0.113.2 203.0.113.3
                   </RequireAny>
               </Location>
               ExtendedStatus On
           </IfModule>








         Note: If "mod_status" is loaded into the server, its handler capability will be available in all configuration files, including per-directory files (for example, .htaccess). This may have security-related ramifications for your website.









    5.


       Restart Apache:





       •


         for CentOS/RHEL-based distributions:




         # service httpd restart





       •


         for Debian/Ubuntu-based distributions:




         # service apache2 restart








       Server statistics will now be available at http://your.server.ip.address/server-status






17. Installing ConfigServer Security & Firewall (CSF)

    Config Server Firewall (CSF) is a Stateful Packet Inspection (SPI) firewall, Login/Intrusion Detection and Security application for Linux servers.
    It's is a security tool that can protect your server against attacks, such as brute force, and improve server security.




    This application will work as a WHM plugin and is free. Follow these instructions to complete a basic CSF installation:






    1. Install CSF: Log into your server as root, using SSH.




       cd /usr/local/src/
       wget https://download.configserver.com/csf.tgz
       tar -xzf csf.tgz
       cd csf
       sh install.sh




       You will see "Installation Completed".




       cd ..
       rm -Rfv csf/ csf.tgz










    2.


       Configure CSF:  Login to your server via WHM as root  and go to the bottom left menu. In the Plugins section, go to ConfigServer Security Firewall.








18. How to manage mailbox size in Web Admin edition?

    It is not possible to manage mailbox size via Plesk user interface in Web Admin edition.




    The only way to manage it is through command-line with administrator privileges.




    Examples (both for Linux and Windows):






    •


      set quota to 100M:




      # plesk bin subscription_settings --update example.com -mbox_quota 100M





    •


      Set the mailbox size to the default value:




      Note: default value for subscription is inherited from its service plan




      # plesk bin subscription_settings --update example.com -mbox_quota -1





    • To change the limit for a specific mailbox, use plesk bin mail utility:


      # plesk bin mail --update user@example.com -mbox_quota 50M






19. Which ports to unblock for VPN traffic to pass-through?

    Microsoft RRAS server and VPN client supports PPTP, L2TP/IPSec, SSTP and IKEv2  based VPN connection. PPTP control path is over TCP and data path over GRE. L2TP tunnel traffic is carried over IPSec transport mode and IPSec protocol internally has a control path through IKE and data path over ESP. SSTP control and data path is over TCP. IKEv2 control path is over IKE and data path over ESP.




    So now coming back to original question. There are multiple scenarios:




    1) If RRAS based VPN server is behind a firewall (i.e. a firewall is placed between Internet and RRAS server), then following ports need to be opened (bidirectional) on this firewall to allow VPN traffic to pass through: -






    • For PPTP:



      • IP Protocol=TCP, TCP Port number=1723   <- Used by PPTP control path


      • IP Protocol=GRE (value 47)   <- Used by PPTP data path






    • For L2TP:



      • IP Protocol Type=UDP, UDP Port Number=500    <- Used by IKEv1 (IPSec control path)


      • IP Protocol Type=UDP, UDP Port Number=4500   <- Used by IKEv1 (IPSec control path)


      • IP Protocol Type=ESP (value 50)   <- Used by IPSec data path






    • For SSTP:




    • IP Protocol=TCP, TCP Port number=443   <- Used by SSTP control and data path




    • For IKEv2:



      • IP Protocol Type=UDP, UDP Port Number=500    <- Used by IKEv2 (IPSec control path)


      • IP Protocol Type=UDP, UDP Port Number=4500   <- Used by IKEv2 (IPSec control path)


      • IP Protocol Type=ESP (value 50)   <- Used by IPSec data path










    2) If RRAS server is directly connected to Internet, then you need to protect RRAS server from the Internet side (i.e. only allow access to the services on the public interface that isaccessible from the Internet side). This can be done using RRAS static filters or running Windows Firewall on the public interface (or the interface towards the Internet side). In this scenario following ports need to be opened (bidirectional) on RRAS box to allow VPN traffic to pass through








    • For PPTP:



      • IP Protocol=TCP, TCP Port number=1723  <- Used by PPTP control path


      • IP Protocol=GRE (value 47)  <- Used by PPTP data path






    • For L2TP:




    • IP Protocol Type=UDP, UDP Port Number=500   <- Used by IKEv1 (IPSec control path)


    • IP Protocol Type=UDP, UDP Port Number=4500 <- Used by IKEv1 (IPSec control path)


    • IP Protocol Type=UDP, UDP Port Number=1701  <- Used by L2TP control/data path


    • IP Protocol Type=50  <- Used by data path (ESP)

















    • For SSTP:


    • IP Protocol=TCP, TCP Port number=443   <- Used by SSTP control and data path








    • For IKEv2:


    • IP Protocol Type=UDP, UDP Port Number=500   <- Used by IKEv2 (IPSec control path)


    • IP Protocol Type=UDP, UDP Port Number=4500 <- Used by IKEv2 (IPSec control path)


    • IP Protocol Type=UDP, UDP Port Number=1701  <- Used by L2TP control/data path


    • IP Protocol Type=50 <- Used by data path (ESP)











    Note: Please DO NOT configure RRAS static filters if you are running on the same server RRAS based NAT router functionality. This is because RRAS static filters are stateless and NAT translation requires a stateful edge firewall like ISA firewall.

20. Connecting using PuTTY on Windows workstations

    Configuring PuTTY








    1. In PuTTY, under Session, enter your Host Name







    2. Under Connection choose Data


    3. Enter your username as the Auto-login username






    4. Under SSH, choose 2 from Preferred SSH Protocol Version


    5. Under SSH -> Auth, you will need to specify where your private key can be found. Remember this is where you saved the private key on your local computer. Click Browse to locate the file on your computer.






    6. Under Sessions, type a name (such as "my site") in the Saved Sessions box and click Save.



21. Connecting using SSH on Linux or OSX workstations

    Use the ssh command to connect to your instance. Specify your username and the external IP address for the instance that you want to connect to.




    Download Prive Key from client area and save it to your workstation

    For this example, the private key is at ~/.ssh/my-ssh-key.

    ssh -i ~/.ssh/my-ssh-key USERNAME@IP_ADDRESS




    where:






    • USERNAME is your username


    • IP_ADDRESS is the IP for your Cloud Server.






    If the connection is successful, you can use the terminal to run commands on your instance.




    When you are done, use the exit command to disconnect from the instance.

22. How to create a .ppk from private key on Windows

    Using a Public/Private key to authenticate when logging into SSH can provide added convenience or added security. The Public/Private key can be used in place of a password so that no username/password is required to connect to the server via SSH. Instead the unique public and private key provide the secure authentication. The keys may also be generated with a different password from your cpanel password if desired.






    Generate a ppk file








    1. Download and open PuTTYgen here.


    2. Click Load







    3. Locate the private SSH key that you have downloaded. Note: You will need choose to display All Files* from the menu to the right of the File Name field.


    4. Click the Save private key button to create the ppk file.





Still have questions ?

Visit our Knowledgebase →
